Gantry Machining Center GMC YSM Series
CNC Milling Machine
The double-column machining center has strong rigidity, symmetrical structure, and high stability. Through continuous optimization of the component structure, the dynamic performance of the product is improved.and high-power, high-torque, high-efficiency, and high-precision machining are realized. t is suitable for large-scale processing fields such as shipbuilding, metallurgy, mining machinery, power energy, construction machinery, heavy industry machinery, and more.
The X-axis is driven by a moving nut, and three-point support is used in the middle to maintain the rotation accuracy of the ball screw rod. At the same time, the load capacity is large and the cutting vibration resistance is good. It can improve the dynamic characteristics of the machine tool and increase the accuracy, stability, and service life of the machine tool.
其他信息
| Air Pressure Requirement | 6ˆ8 kg/cm2 |
|---|---|
| Cutting Feedrate | 10 m/min, 6 m/min, 8 m/min |
| Spindle Max Speed | 6000 rpm |
| Tool Changer | 24(Option:40/60) |
| Taper | BBT-50 |
Product Details
YSM-2013/YSM-2015/YSM-2017/YSM-2518/YSM-3018/YSM-3023/YSM-4023/YSM-4027/YSM-6027/YSM-8027
| Model No. | YSM-2013 | YSM-2015 | YSM-2017 | YSM-2518 | YSM-3018 |
| Travel | |||||
| X-Axis | 2000 mm | 2000mm | 2200 mm | 2500 mm | 3000mm |
| Y-Axis | 1300 mm | 1500 mm | 1650 mm | 2000 mm | 2000 mm |
| Z-Axis | 800 mm | 800 mm | 800 mm | 960 mm | 960 mm |
| Spindle nose to worktable | 190-990 mm | 150-950 mm | 250-1050 mm | 140-1140 mm | 140-1140 mm |
| Three-Axis guideway | XY Heavy Load Roller Linear Guideway Z-Axis T-Type Ram Box Way | XY Heavy Load Roller Linear Guideway Z-Axis T-Type Ram Box Way | |||
| Door width | 1300 | 1500 | 1660 | 1800 | 1800 |
| Worktable | |||||
| Worktable Size (L*W) | 2000×1000 mm | 2100×1200 mm | 2000×1300 mm | 2500×1600 mm | 3000×1600 mm |
| Max. Table load | 6 T | 6 T | 8 T | 10 T | 12 T |
| T-Slot | 7-22×150 mm | 7-22×170 mm | 7-22×170 mm | 9-22×180 mm | 9-22×180 mm |
| SPINDLE | |||||
| Spindle Type | BBT-50 | BBT-50 | BBT-50 | BBT-50 | BBT-50 |
| Spindle R.P.M. | 6000 rpm | 6000 rpm | 6000 rpm | 6000 rpm | 6000 rpm |
| Spindle Drive Type | Belt(DDS/Geared) | Belt(DDS/Geared) | Belt(DDS/Geared) | Belt(DDS/Geared) | Belt(DDS/Geared) |
| Feedrate | |||||
| X/Y/Z Rapid Traverse | 12/12/12 m/min | 12/12/12 m/min | 12/12/12 m/min | 12/12/12 m/min | 8/12/12 m/min |
| X/Y/Z/ Cutting Feedrate | 10 m/min | 10 m/min | 10 m/min | 10 m/min | 8 m/min |
| Tool changer | |||||
| Tool changer ATC | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) |
| Motor | |||||
| Spindle Motor | 15/18.5(143-236Nm) kw | 15/18.5(143-236Nm) kw | 15/18.5(143-236Nm) kw | 15/18.5(143-236Nm) kw | 15/18.5(143-236Nm) kw |
| Three-Axis Servo Motor | 3/3/3(36Nm) | 3/3/3(36Nm) | 3/3/3(36Nm) | 3/3/3(36Nm) | 3/3/3(36Nm) |
| Accuracy | |||||
| Accuracy | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm |
| Repeatability | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm |
| Power Required | |||||
| Power Requirement | 40 kva | 40 kva | 40 kva | 45 kva | 45 kva |
| Air Pressure Requirement | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 |
| Others | |||||
| Extemnal Dimensions(LWH) | 6300x4480x4100 mm | 6300x4480x4100 mm | 6670x4650x4490 mm | 7240x4730x5140 mm | 8440x4730x5140 mm |
| Gross Weight | 18.5 t | 20 t | 22 t | 27 t | 30 t |
| Model No. | YSM-3023 | YSM-4023 | YSM-4027 | YSM-6027 | YSM-8027 |
| Travel | |||||
| X-Axis | 3000 mm | 4000 mm | 4000mm | 6000mm | 3000 mm |
| Y-Axis | 2300 mm | 2300 mm | 2700 mm | 2700 mm | 2700 mm |
| Z-Axis | 1000 mm | 1000 mm | 1000 mm | 1000 mm | 1250 mm |
| Spindle nose to worktable | 280-1280 mm | 280-1280 mm | 280-1280 mm | 280-1280 mm | 200-1450 mm |
| Three-Axis guideway | XY Heavy Load Roller Linear Guideway Z-Axis T-Type Ram Box Way | ||||
| Door width | 2300 | 2300 | 2700 | 2700 | 2700 |
| Worktable | |||||
| Worktable Size (L*W) | 3000×2000 mm | 4000×2000 mm | 4000×2300 mm | 6000×2300 mm | 8000×2300 mm |
| Max. Table load | 14 T | 18 T | 18 T | 22 T | 30 T |
| T-Slot | 9-28×200 mm | 9-28×200 mm | 11-28×200 mm | 11-28×200 mm | 11-28×200 mm |
| SPINDLE | |||||
| Spindle Type | BBT-50 | BBT-50 | BBT-50 | BBT-50 | BBT-50 |
| Spindle R.P.M. | 6000 rpm | 6000 rpm | 6000 rpm | 6000 rpm | 6000 rpm |
| Spindle Drive Type | Belt(DDS/Geared) | Belt(DDS/Geared) | Belt(DDS/Geared) | Belt(DDS/Geared) | Belt(DDS/Geared) |
| Feedrate | |||||
| X/Y/Z Rapid Traverse | 8/12/12 m/min | 8/12/12 m/min | 8/10/10 m/min | 8/10/10 m/min | 6/10/10 m/min |
| X/Y/Z/ Cutting Feedrate | 8 m/min | 8 m/min | 8 m/min | 8 m/min | 6 m/min |
| Tool changer | |||||
| Tool changer ATC | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) |
| Motor | |||||
| Spindle Motor | 15/18.5(143-236Nm) kw | 15/18.5(143-236Nm) kw | 15/18.5(143-236Nm) kw | 15/18.5(143-236Nm) kw | 15/18.5(143-236Nm) kw |
| Three-Axis Servo Motor | 3/3/3(36Nm) | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) |
| Accuracy | |||||
| Accuracy | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm |
| Repeatability | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm |
| Power Required | |||||
| Power Requirement | 45 kva | 55 kva | 55 kva | 55 kva | 60 kva |
| Air Pressure Requirement | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 |
| Others | |||||
| Extemnal Dimensions(LWH) | 8800x5560x5600 mm | 10870x5560x5600 mm | 10870x6000x5600 mm | 15350x6000x5600 mm | 17350x6000x5600 mm |
| Gross Weight | 35 t | 42 t | 48 t | 62 t | 80 t |
| Standard Accessories | Options |
| Rigid Tapping | Optical Linear Scale |
| Automatic Lubricating System | CTS |
| Semi-Enclosed Guard | Tool Breakage System |
| Dual LED Work Light | Chip Conveyor System |
| Heat Exchange for Electric Cabinet | Rotary Table |
| Dual-Screw Type Chip Conweyor | Oil Mist Collector |
| Spindle Nose Air Blow | Oil Skimmer |
| LED 3 Color Warning Light | 90° Manual Milling Head |
| Chain Type Chip Conveyor and Cart | Air Conditioner |
| M30 Auto Off | Auto Parts Probe Measuring System |
| Leveling Bolts and Pads | 90Auto Milling Head with AHC |
YSM-3023 /YSM-4023/YSM-4027/YSM-6027/YSM-8027/YSM-3028/YSM-5028/YSM-7028/YSM-5032/YSM-7032/YSM-9032/YSM-5038/YSM-7038/YSM-9038/YSM-5042/YSM-7042/YSM-9042
| Model No. | YSM-3023 | YSM-4023 | YSM-4027 | YSM-6027 | YSM-8027 | YSM-3028 |
| Travel | ||||||
| X-Axis | 3000 mm | 4000mm | 4000 mm | 6000 mm | 8000 mm | 3000 mm |
| Y-Axis | 2300 mm | 2300 mm | 2700 mm | 2700 mm | 2700 mm | 2800 mm |
| Z-Axis | 1000 mm(Optional 1250) | 1000 mm(Optional 1250) | 1000 mm(Optional 1250) | 1000 mm(Optional1250/1500) | ||
| Spindle nose to worktable | 340-1340 mm | 340-1340 mm | 340-1340 mm | 340-1340 mm | 340-1340 mm | 350-1350 mm |
| Three-Axis guideway | XY Heavy Load Roller Linear Guideway Z-Axis Square -Type Ram | XY Heavy Load Roller Linear Guideway Z-Axis Square-Type Ram | XY Heavy Load Roller Linear Guideway Z-Axis square-Type Ram | |||
| Door width | 2300 | 2300 | 2700 | 2700 | 2700 | 2800 |
| Type of Ram | Square-Type Ram(400×460) | Square-Type Ram(400×460) | Square-Type Ram(400×460) | Square-Type Ram(400×460) | Square-Type Ram(400×460) | Square-Type Ram(500×500) |
| Worktable | ||||||
| Worktable Size (L*W) | 3000×2000 mm | 4000×2000 mm | 4000×2300 mm | 6000×2300 mm | 8000×2300 mm | 3400×2200 mm |
| Max. Table load | 14 T | 18 T | 18 T | 22 T | 30 T | 16 T |
| T-Slot | 9-28×200 mm | 9-28×200 mm | 11-28×200 mm | 11-28×200 mm | 11-28×200 mm | 11-28×200 mm |
| SPINDLE | ||||||
| Spindle Type | BBT-50 | BBT-50 | BBT-50 | BBT-50 | BBT-50 | BBT-50 |
| Spindle R.P.M. | 6000 rpm | 6000 rpm | 6000 rpm | 6000 rpm | 6000 rpm | 6000 rpm |
| Spindle Drive Type | DDS | DDS | DDS | DDS | DDS | DDS |
| Feedrate | ||||||
| X/Y/Z Rapid Traverse | 8/10/10 m/min | 8/10/10 m/min | 8/10/10 m/min | 8/10/10 m/min | 8/10/10 m/min | 10/10/10 m/min |
| X/Y/Z/ Cutting Feedrate | 8 m/min | 8 m/min | 8 m/min | 8 m/min | 8 m/min | 8 m/min |
| Tool changer | ||||||
| Tool changer ATC | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) |
| Motor | ||||||
| Spindle Motor | 15/18.5(143-236Nm) kw | 15/18.5(143-236Nm) kw | 15/18.5(143-236Nm) kw | 22/26(140-286Nm) kw | 22/26(140-286Nm) kw | 22/26(143-236Nm) kw |
| Three-Axis Servo Motor | 3/3/3(36Nm) | 3/3/3(36Nm) | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) |
| Accuracy | ||||||
| Accuracy | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm |
| Repeatability | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm |
| Power Required | ||||||
| Power Requirement | 45 kva | 55 kva | 55 kva | 55 kva | 60 kva | 45 kva |
| Air Pressure Requirement | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 |
| Others | ||||||
| Extemnal Dimensions(LWH) | 8800x5560x5720 mm | 10870x5560x5720 mm | 10870x6000x5720 mm | 15350x6000x5720 mm | 20100x6000x6325 mm | 8800x6050x5820(6320) mm |
| Gross Weight | 36 t | 42.5 t | 48 t | 62 t | 80 t | 45 t |
| Model No. | YSM-5028 | YSM-7028 | YSM-5032 | YSM-7032 | YSM-9032 | YSM-5038 |
| Travel | ||||||
| X-Axis | 5000 mm | 7000 mm | 5000 mm | 7000 mm | 9000 mm | 5000 mm |
| Y-Axis | 2800 mm | 2800 mm | 3200 mm | 3200 mm | 3200 mm | 3800 mm |
| Z-Axis | 1000 mm(Optional1250/1500) | 1000 mm(Optional1250/1500) | ||||
| Spindle nose to worktable | 350-1350 mm | 350-1350 mm | 350-1350 mm | 350-1350 mm | 350-1350 mm | 350-1600 mm |
| Three-Axis guideway | XY Heavy Load Roller Linear Guideway Z-Axis square-Type Ram | XY Heavy Load Roller Linear Guideway Z-Axis square-Type Ram | ||||
| Door width | 2800 | 2800 | 3200 | 3200 | 3200 | 3800 |
| Type of Ram | Square-Type Ram(500×500) | Square-Type Ram(500×500) | ||||
| Worktable | ||||||
| Worktable Size (L*W) | 4600×2200 mm | 6400×2200 mm | 4600×2600 mm | 6400×2600 mm | 8800×2600 mm | 4600×3000 mm |
| Max. Table load | 22 T | 28 T | 25 T | 30 T | 38 T | 30 T |
| T-Slot | 11-28×200 mm | 11-28×200 mm | 13-28×200 mm | 13-28×200 mm | 13-28×200 mm | 15-28×200 mm |
| SPINDLE | ||||||
| Spindle Type | BBT-50 | BBT-50 | BBT-50 | BBT-50 | BBT-50 | BBT-50 |
| Spindle R.P.M. | 6000 rpm | 6000 rpm | 6000 rpm | 6000 rpm | 6000 rpm | 6000 rpm |
| Spindle Drive Type | DDS | DDS | DDS | DDS | DDS | DDS |
| Feedrate | ||||||
| X/Y/Z Rapid Traverse | 10/10/10 m/min | 6/10/10 m/min | 10/10/10 m/min | 6/10/10 m/min | 6/10/10 m/min | 8/10/10 m/min |
| X/Y/Z/ Cutting Feedrate | 8 m/min | 6 m/min | 8 m/min | 6 m/min | 6 m/min | 8 m/min |
| Tool changer | ||||||
| Tool changer ATC | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) |
| Motor | ||||||
| Spindle Motor | 22/26(140-286Nm) kw | 22/26(140-286Nm) kw | 22/26(140-286Nm) kw | 22/26(140-286Nm) kw | 22/26(140-286Nm) kw | 22/26(140-286Nm) kw |
| Three-Axis Servo Motor | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) |
| Accuracy | ||||||
| Accuracy | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm |
| Repeatability | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm |
| Power Required | ||||||
| Power Requirement | 55 kva | 55 kva | 55 kva | 55 kva | 60 kva | 55 kva |
| Air Pressure Requirement | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 |
| Others | ||||||
| Extemnal Dimensions(LWH) | 11600x6050x5820(6320) mm | 15600x6050x5820(6320) mm | 11600x6450x5820(6320) mm | 15600x6450x5820(6320) mm | 19600x6450x5820 mm | 11600x7000x6320 mm |
| Gross Weight | 51 t | 63 t | 56 t | 66 t | 76 t | 66 t |
| Model No. | YSM-7038 | YSM-9038 | YSM-5042 | YSM-7042 | YSM-9042 |
| Travel | |||||
| X-Axis | 7000 mm | 9000 mm | 5000 mm | 7000 mm | 9000 mm |
| Y-Axis | 3800 mm | 3800 mm | 4200 mm | 4200 mm | 4200 mm |
| Z-Axis | 1000 mm(Optional1250/1500) | ||||
| Spindle nose to worktable | 350-1600 mm | 350-1600 mm | 350-1600 mm | 350-1600 mm | 350-1600 mm |
| Three-Axis guideway | XY Heavy Load Roller Linear Guideway Z-Axis square-Type Ram | ||||
| Door width | 3800 | 3800 | 4200 mm | 4200 mm | 4200 mm |
| Type of Ram | Square-Type Ram(500×500) | ||||
| Worktable | |||||
| Worktable Size (L*W) | 6400×3000 mm | 8800×3000 mm | 4600×3000 mm | 6400×3000 mm | 8800×3000 mm |
| Max. Table load | 42 T | 52 T | 30 T | 42 T | 52 T |
| T-Slot | 15-28×200 mm | 15-28×200 mm | 15-28×200 mm | 15-28×200 mm | 15-28×200 mm |
| SPINDLE | |||||
| Spindle Type | BBT-50 | BBT-50 | BBT-50 | BBT-50 | BBT-50 |
| Spindle R.P.M. | 6000 rpm | 6000 rpm | 6000 rpm | 6000 rpm | 6000 rpm |
| Spindle Drive Type | DDS | DDS | DDS | DDS | DDS |
| Feedrate | |||||
| X/Y/Z Rapid Traverse | 6/10/10 m/min | 6/10/10 m/min | 8/10/10 m/min | 6/10/10 m/min | 6/10/10 m/min |
| X/Y/Z/ Cutting Feedrate | 6 m/min | 6 m/min | 8 m/min | 6 m/min | 6 m/min |
| Tool changer | |||||
| Tool changer ATC | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) | 24(Option:40/60) |
| Motor | |||||
| Spindle Motor | 22/26(140-286Nm) kw | 22/26(140-286Nm) kw | 22/26(140-286Nm) kw | 22/26(140-286Nm) kw | 22/26(140-286Nm) kw |
| Three-Axis Servo Motor | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) | 6/3/3(38/36/36Nm) |
| Accuracy | |||||
| Accuracy | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm | 0.03/0.02/0.015 mm |
| Repeatability | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm | 0.02/0.015/0.01mm |
| Power Required | |||||
| Power Requirement | 60 kva | 60 kva | 55 kva | 60 kva | 60 kva |
| Air Pressure Requirement | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 | 6ˆ8 kg/cm2 |
| Others | |||||
| Extemnal Dimensions(LWH) | 15600x7000x6320 mm | 19600x7000x6320 mm | 11600x8000x6320 mm | 15600x8000x6320 mm | 19600x8000x6320 mm |
| Gross Weight | 77 t | 91 t | 70 t | 82 t | 95 t |
| Standard Accessories | Options |
| Spindle Coolant System | Optical Linear Scale |
| Automatic Lubricating System | CTS |
| Semi-Enclosed Guard | 20T/40T/60TATC |
| Rigid Tapping | Workpieces Probe |
| Heat Exchange for Electric Cabinet | Chip Conveyor System |
| Dual-Screw Type Chip Conweyor | Rotary Table |
| Dual LED Work Light | Oil Mist System |
| LED 3 Color Warning Light | Oil Skimmer |
| Chain Type Chip Conveyor and Cart | Air Conditioner |
| Geared Box | Manual/Semi-Auto 90” Milling Head |
| Leveling Bolts and Pads | Auto Parts Probe Measuring System |
| M30 Auto Off | |
