Vertical Machining Center VMC YS650-5AX
CNC Milling Machine
The machine tool of this product is equipped with name brand components in the industry, equippedwith a large torque, high speed motor and a super rigid bed design.Taking into account high torque, high speed and high precision, it is suitable for processing allkinds of products and molds.
其他信息
| Air Pressure Requirement | 6ˆ8 kg/cm2 |
|---|---|
| Weight | 12 TON |
| Taper | HSKA63 |
| Spindle Max Speed | 18000 rpm |
| Cutting Feedrate | 10 m/min |
Product Details
| Model No. | YS650-5AX |
| Travel | |
| X/Y/Z axis | 700X450X400 mm |
| Spindle Noseto Worktable | 200-600 mm |
| Spindle Center to Column | 400 mm |
| Three-Axis Guideway | Roller Linear Guideway |
| Worktable | |
| Worktable Size (L*W) | Ø650 mm |
| Maximum Table Load | 200 kg |
| T-Slot | 5-18×100 mm |
| Worktable indexing | 0.001° |
| SPINDLE | |
| Spindle taper | HSKA63 |
| Spindle speed | 18000 rpm |
| Spindle Drive Type | Built-In |
| Feedrate | |
| Rapid Traverse(XY/Z) | 30/30/30 m/min |
| Cutting FeedrateXYIZ | 10m/min |
| Tool changer | |
| Automatic Tool Changer | ARM Type |
| Motor | |
| Spindle Motor | 20 kw |
| Three-Axs Servo Miolor | 3.0/3.0/3.0 kw |
| Accuracy | |
| Accuracy | ±0.005 mm |
| Repeatability | ±0.003 mm |
| Power Required | |
| Power Requirement | 30 kva |
| Air PressureRequirement | 6ˆ8 kg/cm2 |
| Others | |
| Extemnal Dimensions(LWH) | / |
| Gross Weight | 12t |
| Standard Accessories | Options |
| Safety Door | Optical Linear Scale |
| Heat Exchange for Electric Cabinet | Oil Skimmer |
| Coclant Tank & Chip Tray | Tool Breakage System |
| Dual LED Work Light | Workpiece & Tool Probe |
| LED 3 Color Warning Light | Oil Mist Collector |
| Air Gun | Arm Type Tool Changer |
| Spindle Nose Air Blow | CTS |
| Leveling Bolts and Pads | |
| Coolant Gun | |
| Automatic Lubricating System | |
| Fully Enclosure Guard | |
| M30 Auto Off | |
