Vertical Machining Center VMC YSCP-835
CNC Milling Machine
The machine tool of this product is equipped with name brand components in the industry, equippedwith a large torque, high speed motor and a super rigid bed design.Taking into account high torque, high speed and high precision, it is suitable for processing allkinds of products and molds.
其他信息
| Air Pressure Requirement | 6ˆ8 kg/cm2 |
|---|---|
| Weight | 5 TON |
| Cutting Feedrate | 10 m/min |
| Max Table Load | 1000 kg |
| Power Requirement | 10 kva |
Product Details
| Model No. | YSCP-835 |
| Travel | |
| X/Y/Z axis | 800X450 mm |
| Spindle Noseto Worktable | 250-700 mm |
| Spindle Center to Column | 740 mm |
| Three-Axis Guideway | Roller Linear Guideway |
| Worktable | |
| Worktable Size (L*W) | 800x700mm |
| Maximum Table Load | 1000 kg |
| T-Slot | 5-18×120 mm |
| Worktable indexing | / |
| SPINDLE | |
| Spindle taper | / |
| Spindle speed | / |
| Spindle Drive Type | Built-In |
| Feedrate | |
| Rapid Traverse(XY/Z) | 10/10 m/min |
| Cutting FeedrateXYIZ | 10m/min |
| Tool changer | |
| Automatic Tool Changer | / |
| Motor | |
| Spindle Motor | / |
| Three-Axs Servo Miolor | 3.0/3.0 kw |
| Accuracy | |
| Accuracy | ±0.005 mm |
| Repeatability | ±0.003 mm |
| Power Required | |
| Power Requirement | 10 kva |
| Air PressureRequirement | 6ˆ8 kg/cm2 |
| Others | |
| Extemnal Dimensions(LWH) | 3000x2500x2300mm |
| Gross Weight | 5t |
| Standard Accessories | Options |
| Safety Door | Optical Linear Scale |
| Heat Exchange for Electric Cabinet | Oil Skimmer |
| Coclant Tank & Chip Tray | Tool Breakage System |
| Dual LED Work Light | Workpiece & Tool Probe |
| LED 3 Color Warning Light | Oil Mist Collector |
| Air Gun | Arm Type Tool Changer |
| Spindle Nose Air Blow | CTS |
| Leveling Bolts and Pads | |
| Coolant Gun | |
| Automatic Lubricating System | |
| Fully Enclosure Guard | |
| M30 Auto Off | |
